| Working Range | Max. Machining Diameter | mm | Φ300 | Φ400 | Φ500 |
| Machining Length Range | mm | 300–1200 | 800–1800 | 1300–2300 |
| Travel | Max. Working Travel of X-axis | mm | 200 | 250 | 300 |
| Max. Working Travel of Z-axis | mm | Left 700, Right 1000 | Left 700, Right 1200 | Left 700, Right 1450 |
| Spindle | Spindle Through-Hole Diameter | mm | Φ300 | Φ400 | Φ500 |
| Spindle Speed Range | m/min | 50–1500 | 50–1000 | 50–500 |
| Main Motor Power | kW | 15 | 22 | 22 |
| Tool Turret | Tool Turret Type | / | 8/12-station tool turret | 8/12-station tool turret | 8/12-station tool turret |
| Feed | Rapid Traverse Speed of X-axis | mm | 10000 | 10000 | 10000 |
| Rapid Traverse Speed of Z-axis | mm | 10000 | 10000 | 10000 |
| Accuracy | Positioning Accuracy of XZ | mm | ≤0.015 | ≤0.015 | ≤0.015 |
| Repeat Positioning Accuracy of XZ | mm | 0.01 | 0.01 | 0.01 |
| System | CNC System | / | 0i TF Plus | 0i TF Plus | 0i TF Plus |
| Power Supply | Power Supply | KVA | ≥30 | ≥45 | ≥50 |
| Machine Dimensions | Floor Space (L×W×H) | mm | 4900×2400×2500 | 5900×2400×2500 | 6900×2400×2500 |
| Machine Weight (Approx.) | kg | 9500 | 12500 | 15500 |
